Description
5kW Deye Hybrid Inverter + Wi-Fi Dongle
The 5kW Deye Hybrid Inverter + Wi-Fi Dongle is designed to coordinate solar generation, compatible battery storage and grid power in one energy-management platform. It is suited to professionally designed backup and self-consumption systems for homes, businesses or commercial sites, depending on its rated capacity and phase configuration.
Key Features
- Coordinates solar, compatible battery storage and grid power in a single system.
- Supports professional system monitoring and protection when installed with the required accessories.
- Suitable for integration into an engineered solar power system.
Technical Specifications
| Brand | Deye |
|---|---|
| Product | 5kW Deye Hybrid Inverter + Wi-Fi Dongle |
| Product category | Inverters |
| Rated inverter power | 5kW |
| Operating type | Hybrid inverter |
| 5kW 3-Phase Hybrid Inverter | Provides a robust and reliable solution for small to medium-sized solar power systems, delivering clean, stable power to your electrical system. |
| Grid-Tied and Off-Grid Capabilities | Works seamlessly in both grid-tied and off-grid configurations, allowing for maximum flexibility and energy independence. |
| Wide MPPT Voltage Range | Supports a wide MPPT voltage range of 180V to 850V, allowing for flexibility in solar panel configurations and ensuring maximum compatibility. |
| Built-in Battery Management System (BMS) | Integrates with a wide range of battery types, including lithium-ion, lead-acid, and more, ensuring optimal performance and extended battery life. |
| User-Friendly Interface | A clear LCD display and straightforward button layout make it easy to monitor system performance and configure settings. |
| Model | 5kW 3-Phase Deye Hybrid Inverter |
| Rated Power | 5kW |
| Input Voltage Range | 180V – 850V |
| Max. PV Array Open Circuit Voltage | 1000V |
| MPPT Operating Voltage Range | 180V – 800V |
| Max. PV Input Power | 7.5kW |
Suitable Applications
- Residential solar and backup systems
- Small offices, shops and farms
- Solar self-consumption installations
- Off-grid or grid-connected applications, according to inverter type
Important Installation Information
Installation must be completed by a qualified electrician or solar installer. Confirm the exact model, battery compatibility, PV string voltage, input current, phase configuration, cable sizing, breakers, surge protection, earthing and local grid requirements before installation.
