6kW Deye Off-Grid Inverter
The Deye 6kW Off-Grid Inverter is a single-phase power-conversion platform for residential, farm and small-business backup or off-grid installations. It combines high-voltage PV input, 48V-class battery support and fast backup transfer in an IP65 enclosure.
Key Features
- 6,000W continuous pure sine wave AC output.
- Peak output of up to 12,000W for 10 seconds for short start-up loads.
- Two independent MPPT trackers for flexible PV string design.
- Supports lithium-ion and lead-acid batteries in the 40V to 60V range.
- Grid and generator input support with compatible generator control.
- Wi-Fi, Bluetooth, CAN and RS485 communication support.
- Designed for battery-backed and off-grid AC power applications.
- Supports professional system monitoring and protection when installed with the required accessories.
Technical Specifications
| Brand | Deye |
|---|---|
| Product | 6kW Deye Off-Grid Inverter |
| Product category | Inverters |
| Rated inverter power | 6kW |
| Operating type | Off-grid inverter |
| Model | SUN-6K-OG01LP1-EU-AM2 |
| Rated AC output | 6,000W |
| Peak output | 12,000W for 10 seconds |
| Battery voltage range | 40V to 60V DC |
| Maximum charge/discharge current | 135A |
| MPPT trackers | 2 |
| Maximum connected PV capacity | 12,000W |
| Maximum usable PV input | 9,600W |
| Maximum PV input voltage | 500V DC |
| Ingress protection | IP65 |
Suitable Applications
- Residential solar and backup systems
- Small offices, shops and farms
- Solar self-consumption installations
- Off-grid or grid-connected applications, according to inverter type
Important Installation Information
Installation must be completed by a qualified electrician or solar installer. Confirm the exact model, battery compatibility, PV string voltage, input current, phase configuration, cable sizing, breakers, surge protection, earthing and local grid requirements before installation.
