Description
technical specifications for the Canadian Solar 540W solar panel:
- Maximum Power (Pmax): 540W
- Open Circuit Voltage (Voc): 51.7V
- Short Circuit Current (Isc): 15.75A
- Maximum Power Voltage (Vmp): 42.5V
- Maximum Power Current (Imp): 12.71A
- Module Efficiency: 21.4%
- Operating Temperature: -40°C to +85°C
- Maximum System Voltage: 1500V (UL) / 1000V (IEC)
- Maximum Series Fuse Rating: 25A
- Dimensions: 2275mm x 1134mm x 35mm
- Weight: 32.6 kg
- Cell Type: Monocrystalline
- Number of Cells: 144 (6 x 24)
- Glass: 3.2mm, High Transmission, AR Coated Tempered Glass
- Frame: Anodized Aluminum Alloy
- Junction Box: IP68, 3 diodes
- Cable: 4mm² (IEC) / 12 AWG (UL), 1200mm length
The Canadian Solar 540W solar panel uses monocrystalline cell technology, which allows for higher efficiency and power output. With an efficiency rating of 21.4%, this panel is able to convert a high percentage of the sunlight it receives into usable electricity. It has a durable design that can withstand harsh weather conditions, and comes with a reliable warranty. The panel has a maximum system voltage of 1500V (UL) / 1000V (IEC) and a maximum series fuse rating of 25A. It has dimensions of 2275mm x 1134mm x 35mm and a weight of 32.6 kg, making it a versatile and easy-to-install option for a variety of solar applications. The panel has a tempered glass front with anti-reflective coating and an anodized aluminum alloy frame for protection. The junction box is IP68 rated and has 3 bypass diodes for improved performance. The cable is 1200mm in length and has a cross-sectional area of 4mm² (IEC) / 12 AWG (UL).
Overall, the Canadian Solar 540W solar panel is a high-performance and durable choice for solar applications, with impressive efficiency and power output, and a reliable warranty. It is suitable for a wide range of applications, from residential to commercial and utility-scale projects. It is compatible with most standard mounting systems and has a versatile design that can adapt to different installation needs. The panel is designed to withstand harsh weather conditions and provide reliable performance for many years.
