Description
3.2 kW Hzsolar Hybrid Inverter Specifications
Key Features & Benefits
- Pure sine-wave output for sensitive electronics
- 3.2 kVA / 3.2 kW continuous AC power
- Integrated MPPT charge controller for maximum PV harvest
- Battery-only cold-start capability
- Compact wall-mount design for easy installation
Electrical Specifications
| Parameter | Specification |
|---|---|
| Rated AC Output | 3.2 kVA / 3.2 kW |
| AC Voltage | 230 VAC ± 2 % |
| Frequency | 50 Hz |
| Total Harmonic Distortion (THD) | < 3 % |
| Peak Efficiency | > 93 % |
PV Input (MPPT)
| Parameter | Specification |
|---|---|
| MPPT Channels | 1 |
| Maximum PV Input Voltage | 450 V DC |
| Maximum PV Input Power | 3 000 W |
| Solar Panel Configuration | 2–6 × 560 W panels in series (single string) |
| 2–7 × 460 W panels in series (single string) |
Note: Only one series string per MPPT channel; parallel strings are not supported.
Battery Requirements
| Parameter | Specification |
|---|---|
| Battery Voltage | 24 V LiFePO₄ |
| Recommended Configuration | 2 × 24 V battery modules in parallel |
| Low-Voltage Cut-Off (LVD) | 23.4 V |
Using matched 24 V batteries in parallel helps extend cycle life and maintain stable voltage under load.
Operation and Control
- Start-Up Modes: Cold start from battery
- Display: Built-in LCD for real-time PV, battery, and load status
- Protections: Over-voltage, under-voltage, over-current, short-circuit, anti-islanding
Environmental and Mechanical
| Parameter | Specification |
|---|---|
| Operating Temperature | –10 °C to 50 °C |
| Humidity Range | 0 % to 95 % (non-condensing) |
| Ingress Protection | IP20 |
| Dimensions | See manufacturer datasheet |
| Weight | See manufacturer datasheet |
Warranty and Certification
- Warranty: 2 years (extendable)
- Certifications: CE, RoHS, IEC 62109
