Description
Key Specifications:
- Rated Power: 5kW (5000W)
- Input Voltage Range (PV): 60-115VDC or 120-430VDC (depending on the model)
- Maximum PV Input Power: 5000W
- Output Voltage: 230VAC (±5%)
- Output Frequency: 50Hz or 60Hz (±0.3Hz)
- Battery Voltage: 48VDC
- Maximum Charging Current: 80A (adjustable)
Key Features:
- Pure Sine Wave Output: Provides clean and stable power, suitable for sensitive electronic equipment.
- Hybrid Functionality: Combines solar power, grid power, and battery power for a complete energy solution.
- MPPT Solar Charge Controller: Integrated Maximum Power Point Tracking (MPPT) technology ensures maximum efficiency in solar energy conversion.
- Wide PV Input Range: Allows for flexibility in solar panel installation and power generation.
- AC/Grid Input: Offers an option to charge the battery using grid power when solar power is insufficient.
- Automatic Transfer Switch (ATS): Switches seamlessly between solar, battery, and grid power, ensuring continuous power supply.
- Smart Battery Management: Protects and extends battery life by using appropriate charging algorithms.
- Overload, Short Circuit, and Surge Protection: Safeguards the inverter and connected devices from damage caused by power irregularities.
- LCD Display: Provides real-time information on input/output voltage, battery status, solar power, and other essential parameters.
- Remote Monitoring: Some models offer remote monitoring and control via a mobile app or web portal.
- Fan Cooling: Built-in fan to maintain optimal temperature and prolong the inverter’s lifespan.
- Certifications: Compliant with international safety and performance standards such as CE, IEC, and RoHS.
Please note that the specific features and specifications mentioned above might vary depending on the exact model of the Must Power PV18-5K Hybrid Inverter. It’s essential to consult the user manual or contact the manufacturer for accurate product details.
